Rosemount 2051L Wireless Level Transmitter
Confidently measure pressure and level with the Rosemount 3051 In-Line Pressure Transmitter. Engineered for 10-year installed stability and 0.04% of span accuracy, this industry-leading pressure transmitter provides you with the information necessary to run, control and monitor processes. Available with a graphical, back-lit display, Bluetooth® connectivity, and enhanced software capabilities designed to access the data you need faster than ever before.
Specifications
| Warranty | Up to 5-year limited warranty |
| Rangedown | Up To 100:1 |
| Communication Protocol | WirelessHART® |
| Measurement Range | Up to 10000 psig (689,47 bar) Gage, Up to 10000 psia (689,47bar) Absolute |
| Process Wetted Material | 316L SST, Alloy C-276 |
| Diagnostics | Basic Diagnostics |
| Certifications/Approvals | NSF, NACE®, hazardous location, see full specs for complete list of certifications |
| Update Rate | 1 sec. to 60 min., user selectable |
| Power Module Life | Up to 10-year life, field replaceable (order separately) |
| Wireless Range | Internal antenna (225 m) |
Features
- WirelessHART® technology is secure, cost-effective and delivers >99% data reliability
- Tuned-System Level assembly and direct mounting produce optimal performance for level applications
- Optimized seal system construction ensures a quality measurement in harsh process conditions
- SmartPower module provides up to 10-year maintenance-free operation and field replacement without transmitter removal
- Easy installation enables quick instrumentation of measurement points without the cost of wiring
